Capacitive sensors CM18
Home Products Proximity Photoelectric SensorCapacitive proximity sensorsCapacitive sensors CM18
Product Details
Capacitive sensors CM18
| Model NO. | Detection distance | Working voltage | Output | Flush | |
| Form | State | ||||
| CM18-3005NA | 0 -5mm | DC6-36V | NPN | NO | Flush |
| CM18-3005NB | 0 -5mm | DC6-36V | NPN | NC | Flush |
| CM18-3005NC | 0 -5mm | DC6-36V | NPN | NO NC | Flush |
| CM18-3005PA | 0 -5mm | DC6-36V | PNP | NO | Flush |
| CM18-3005PB | 0 -5mm | DC6-36V | PNP | NC | Flush |
| CM18-3005PC | 0 -5mm | DC6-36V | PNP | NO NC | Flush |
| CM18 -2005A | 0 -5mm | AC90-250V | SCR Control lable silicon | NO | Flush |
| CM18-2005B | 0 -5mm | AC90-250V | SCR Control lable silicon | NC | Flush |
| CM18-3008NA | 0 -8mm | DC6-36V | NPN | NO | Non-flush |
| CM18-3008NB | 0 -8mm | DC6-36V | NPN | NC | Non-flush |
| CM18-3008NC | 0 -8mm | DC6-36V | NPN | NO NC | Non-flush |
| CM18-3008PA | 0 -8mm | DC6-36V | PNP | NO | Non-flush |
| CM18-3008PB | 0 -8mm | DC6-36V | PNP | NC | Non-flush |
| CM18-3008PC | 0 -8mm | DC6-36V | PNP | NO NC | Non-flush |
| CM18 -2008A | 0 -8mm | AC90-250V | SCR Control lable silicon | NO | Non-flush |
| CM18-2008B | 0 -8mm | AC90-250V | SCR Control lable silicon | NC | Non-flush |
