CLS Miniature Limit Switch (economical type)
|
Model |
CLS |
CLS101
CLS301
|
CLS102
CLS103 CLS302 CLS303 |
CLS111 CLS311
|
CLS121
CLS121M CLS321 CLS321M |
CLS127
CLS327 |
CLS131
CLS131M CLS331 CLS331M |
CLS161
CLS361 |
CLS171
CLS371 |
CLS181
CLS381 |
CLS391
CLS191 |
|
Operating force |
OF(Max.) |
700g |
700g |
700g |
500g |
700g |
500g |
100g |
100g |
100g |
500g |
|
Release force |
RF(Min.) |
200g |
200g |
200g |
100g |
200g |
100g |
40g |
40g |
40g |
100g |
|
Pre-travel |
PT(Max.) |
1.8mm |
1.8mm |
1.8mm |
20° |
1.8mm |
20° |
30mm |
30mm |
30mm |
20° |
|
Tripping position |
TP±10% |
2.0mm |
2.0mm |
2.0mm |
22.5° |
2.0mm |
22.5° |
22.5° |
22.5° |
22.5° |
22.5° |
|
Movement differential |
MD(Max.) |
1.2mm |
1.2mm |
1.2mm |
10° |
1.2mm |
10° |
14° |
14° |
14° |
10° |
|
Over travel |
OT(Min.) |
3.7mm |
3.7mm |
3.7mm |
75° |
3.7mm |
75° |
20mm |
20mm |
20mm |
75° |
|
Total travel |
TT (Min.) |
5.5mm |
5.5mm |
5.5mm |
95° |
5.5mm |
95° |
50mm |
50mm |
50mm |
95° |
|
Rotary indexing |
|
|
|
|
22.5° |
|
22.5° |
|
|
|
22.5° |
