Fast thyristor
Type |
IT(AV) |
VDRM/VRRM |
IT(A) |
IDRM/IRRM Tj=125℃ |
VTM(max) |
Tq(max) |
Tvj |
Rthjc |
F±10% |
Outline |
|
ITM |
VTM |
||||||||||
A |
V |
KA |
mA |
A |
V |
μs |
℃ |
K/W |
KN |
||
C476 |
200 |
600-1400 |
5.5 |
35 |
1200 |
2.5 |
20 |
125 |
0.06 |
10 |
KT30 |
C448 |
700 |
600-1400 |
9.1 |
35 |
2000 |
2.9 |
40 |
125 |
0.04 |
15 |
KT40 |
C612 |
700 |
1600-2000 |
9.0 |
60 |
2000 |
2.21 |
60 |
125 |
0.04 |
15 |
KT40 |
C613 |
500 |
1600-2000 |
6.5 |
60 |
2000 |
2.9 |
50 |
125 |
0.04 |
15 |
KT40 |
C458 |
1200 |
600-1400 |
14.6 |
65 |
3000 |
2.35 |
40 |
125 |
0.02 |
25 |
KT55 |
C712 |
1125 |
1600-2000 |
20 |
60 |
1000 |
1.45 |
55 |
125 |
0.02 |
25 |
KT55 |
C714 |
925 |
2000 |
14.7 |
60 |
1000 |
1.95 |
45 |
125 |
0.02 |
25 |
KT55 |
C770 |
2100 |
1800 |
35 |
100 |
2000 |
1.55 |
80 |
125 |
0.01 |
36 |
KT80 |
