Product Details
Single phase half controlled bridge rectifier 40A to 150A
MODEL | IFAV | VFM | VRRM | IRRM | IFSM |
A | V | V | mA | A | |
MFQ-40-08 | 40 | 1.6 | 800 | 8 | 480 |
MFQ-40-12 | 40 | 1.6 | 1200 | 8 | 480 |
MFQ-40-16 | 40 | 1.6 | 1600 | 8 | 480 |
MFQ-40-18 | 40 | 1.6 | 1800 | 8 | 480 |
MFQ-50-08 | 50 | 1.6 | 800 | 8 | 600 |
MFQ-50-12 | 50 | 1.6 | 1200 | 8 | 600 |
MFQ-50-16 | 50 | 1.6 | 1600 | 8 | 600 |
MFQ-50-18 | 50 | 1.6 | 1800 | 8 | 600 |
MFQ-60-08 | 60 | 1.6 | 800 | 8 | 720 |
MFQ-60-12 | 60 | 1.6 | 1200 | 8 | 720 |
MFQ-60-16 | 60 | 1.6 | 1600 | 8 | 720 |
MFQ-60-18 | 60 | 1.6 | 1800 | 8 | 720 |
MFQ-100-08 | 100 | 1.6 | 800 | 8 | 1000 |
MFQ-100-12 | 100 | 1.6 | 1200 | 8 | 1000 |
MFQ-100-16 | 100 | 1.6 | 1600 | 8 | 1000 |
MFQ-100-18 | 100 | 1.6 | 1800 | 8 | 1000 |
MFQ-150-08 | 150 | 1.6 | 800 | 10 | 1500 |
MFQ-150-12 | 150 | 1.6 | 1200 | 10 | 1500 |
MFQ-150-16 | 150 | 1.6 | 1600 | 10 | 1500 |
MFQ-150-18 | 150 | 1.6 | 1800 | 10 | 1500 |
