LSY10-130-107 Three-phase integrated transformer
Home Products Medium Voltage CT & PTThree-phase integrated transformerLSY10-130-107 Three-phase integrated transformer
Overview
LSY10-130-107 Three-phase integrated transformer
Power factor: COCφ=0.8
Frequency: 50Hz or 60Hz
Rated short time thermal current Ith: 40KA,2S
Rated continuous thermal current:1200%In
Measuring: FS<10
Protection: 10P10, 10P15, 10P20
Product Details
Model | Application |
Rated
secondary
current
|
Measuring CT | Protection CT | Double winding CT | |||
Rated
primary
current
|
Accuracy & rated
capacity VA |
Accuracy & rated
capacity VA |
Accuracy & rated
capacity VA |
|||||
0.2S | 0.2 | 0.5 | 10P10 | 0.5 | 10P10 | |||
LSY10-130-107 | 75 |
5A
1A
|
/ | / | 1 | / | 1 | / |
100 | / | / | 2.5 | / | 1 | / | ||
150 | / | / | 2.5 | 2.5 | 1.5 | / | ||
200 | / | 2.5 | 2.5 | 5 | 2.5 | 5 | ||
300 | 2.5 | 2.5 | 5 | 5 | 2.5 | 5 | ||
400 | 5 | 5 | 5 | 7.5 | 5 | 7.5 | ||
500 | 5 | 5 | 10 | 10 | 5 | 10 | ||
600 | 5 | 10 | 10 | 10 | 5 | 10 | ||
800 | 10 | 10 | 10 | 10 | 5 | 10 |
