Slim 3 phase Power Diode Module GDF100AA
Power Diode Module DF100AA is designed for three phase full wave rectification, which has six diodes connected in a three phase bridge configuration. The mounting base of the module is electrically isolated from semiconductor elements for simple heatsink construction. Output DC current is 100Amp (Tc=102℃) Repetitive peak reverse voltage is up to 1,600V.
![](/UploadFiles/attached/image/20221212/20221212143404_2467.jpg)
Feature:
● TjMax=150℃
● Isolated mounting base
● High reliability by unique glass passivation
Applications:
AC, DC Motor Drive/AVR/Switching -for three phase rectification
