DP-816 Split core Current Transformer
Frequency: 50/60Hz
Withstand voltage: 3kV AC.(1min)
Rated thermal current: 60In
Dynamic stable current: 2.5lth
Rated voltage: 0.72kV AC.
Overload: 0.2Ih
Working temperature range: -10℃ ~ 50℃
Shell flame retardant grade: V0
Accuracy limiting factor: FS5
Secondary current: 5A/1A
Product Details
| Model | Ratio A | Burden VA | |
| Class 0.5 | Class 1.0 | ||
| DP-816 | 1000/5 | 5 | 10 |
| 1500/5 | 7.5 | 10 | |
| 2000/5 | 10 | 15 | |
| 2500/5 | 15 | 20 | |
| 3000/5 | 20 | 25 | |
| 4000/5 | 20 | 25 | |
| 5000/5 | 20 | 25 | |
| 6000/5 | 20 | 25 | |
