Inductive sensors LM24
Home Products Proximity Photoelectric SensorInductive proximity sensor (Cylinder type)Inductive sensors LM24
Product Details
Inductive sensors LM24
Model NO. | Detection distance | Working voltage | Output | Flush | |
Form | State | ||||
LM24-3008NA | 8mm | DC6-36V | NPN | NO | Flush |
LM24-3008NB | 8mm | DC6-36V | NPN | NC | Flush |
LM24-3008NC | 8mm | DC6-36V | NPN | NO NC | Flush |
LM24-3008PA | 8mm | DC6-36V | PNP | NO | Flush |
LM24-3008PB | 8mm | DC6-36V | PNP | NC | Flush |
LM24-3008PC | 8mm | DC6-36V | PNP | NO NC | Flush |
LM24-3008LA | 8mm | DC6-36V | Two wire system | NO | Flush |
LM24 -3008LB | 8mm | DC6-36V | Two wire system | NC | Flush |
LM24 -2008A | 8mm | AC90-250V | SCR Control label silicon | NO | Flush |
LM24-2008B | 8mm | AC90-250V | SCR Control label silicon | NC | Flush |
LM24 -2008C | 8mm | AC90-250V | SCR Control label silicon | NO NC | Flush |
LM24-3010NA | 10mm | DC6-36V | NPN | NO | Non-flush |
LM24-3010NB | 10mm | DC6-36V | NPN | NC | Non-flush |
LM24-3010NC | 10mm | DC6-36V | NPN | NO NC | Non-flush |
LM24-3010PA | 10mm | DC6-36V | PNP | NO | Non-flush |
LM24-3101PB | 10mm | DC6-36V | PNP | NC | Non-flush |
LM24-3010PC | 10mm | DC6-36V | PNP | NO NC | Non-flush |
LM24-3010LA | 10mm | DC6-36V | Two wire system | NO | Non-flush |
LM24 -3010LB | 10mm | DC6-36V | Two wire system | NC | Non-flush |
LM24 -2010A | 10mm | AC90-250V | SCR Control label silicon | NO | Non-flush |
LM24-2010B | 10mm | AC90-250V | SCR Control label silicon | NC | Non-flush |
LM24 -2010C | 10mm | AC90-250V | SCR Control label silicon | NO NC | Non-flush |
