SBL Series Bridge Rectifier
Home Products Diode Bridge RectifierSingle phase bridge rectifier (Fast-on type)SBL Series Bridge Rectifier
SBL Series Bridge Rectifier
|
TYPE |
Repetitive Peak Reverse Voltage |
Maximum
Average
Rectified Current
|
Maximum Forward Peak Surge Current |
Maximum Forward Voltage |
Maximum Reverse Current |
Junction Temperature |
Insulating Voltage |
|||
|
VRRM |
IF(AV)@Tc |
IFSM |
VF @IF |
IRRM @TA |
TJM |
VISO |
||||
|
(V) |
(A) |
(℃) |
(A) |
(V) |
(A) |
25℃(μA) |
125℃(μA) |
(℃) |
(V) |
|
|
S25BL60 |
600 |
25 |
85 |
350 |
1.1 |
12.5 |
5 |
500 |
150 |
2500 |
|
S25BL80 |
800 |
25 |
85 |
350 |
1.1 |
12.5 |
5 |
500 |
150 |
2500 |
|
S25BL100 |
1000 |
25 |
85 |
350 |
1.1 |
12.5 |
5 |
500 |
150 |
2500 |
|
S35BL60 |
1200 |
35 |
85 |
400 |
1.1 |
17.5 |
5 |
500 |
150 |
2500 |
|
S35BL80 |
1400 |
35 |
85 |
400 |
1.1 |
17.5 |
5 |
500 |
150 |
2500 |
|
S35BL100 |
1600 |
35 |
85 |
400 |
1.1 |
17.5 |
5 |
500 |
150 |
2500 |
|
S50BL60 |
600 |
50 |
85 |
500 |
1.1 |
25 |
5 |
500 |
150 |
2500 |
|
S50BL80 |
800 |
50 |
85 |
500 |
1.1 |
25 |
5 |
500 |
150 |
2500 |
|
S50BL100 |
1000 |
50 |
85 |
500 |
1.1 |
25 |
5 |
500 |
150 |
2500 |
