| Standard power ratings of 3-phase motors 50/60 Hz in category AC-3 | Rated operational current in AC-3 up to 440V (A) | Instantaneous auxiliary contacts | Reference | |||||||
| 220V 230V (kW) | 380V 400V (kW) | 415V (kW) | 440V (kW) | 500V (kW) | 660V 690V (kW) | NO | NC | |||
| 2.2 | 4 | 4 | 4 | 5.5 | 5.5 | 9 | 25 | - | 1 | LC2-D0901 |
| 3 | 5.5 | 5.5 | 5.5 | 7.5 | 7.5 | 12 | 25 | - | 1 | LC2-D1201 |
| 4 | 7.5 | 9 | 9 | 10 | 10 | 18 | 32 | - | 1 | LC2-D1801 |
| 5.5 | 11 | 11 | 11 | 15 | 15 | 25 | 40 | - | 1 | LC2-D2501 |
| 7.5 | 15 | 15 | 15 | 18.5 | 18.5 | 32 | 50 | - | 1 | LC2-D3201 |
| 11 | 18.5 | 22 | 22 | 22 | 30 | 40 | 60 | 1 | 1 | LC2-D4011 |
| 15 | 22 | 25 | 30 | 30 | 33 | 50 | 80 | 1 | 1 | LC2-D5011 |
| 18.5 | 30 | 37 | 37 | 37 | 37 | 65 | 80 | 1 | 1 | LC2-D6511 |
| 22 | 37 | 45 | 45 | 45 | 45 | 80 | 125 | 1 | 1 | LC2-D8001 |
| 25 | 45 | 45 | 45 | 45 | 45 | 95 | 125 | 1 | 1 | LC2-D9511 |
