Single phase bridge rectifier 25/35A 26MB120/160 36MB120/160
Home Products Diode Bridge RectifierSingle phase bridge rectifier (Fast-on type)Single phase bridge rectifier 25/35A 26MB120/160 36MB120/160
Product Details
Single phase bridge rectifier 25/35A 26MB120/160 36MB120/160
| Order # | V RRM | I O | @T | I FSM |
| V | A | ℃ | A | |
| 26MB120 | 1200 | 25 | 55 | 300 |
| 26MB160 | 1600 | 25 | 55 | 300 |
| 36MB120 SKB35-12 | 1200 | 35 | 55 | 400 |
| 36MB160 SKB35-16 | 1600 | 35 | 55 | 400 |
Inquiry
Need more information?
Contact us to request pricing, availability and customization options.
