| Standard conformity | IEC:60947-3:2001 | ||
| Type/Series | 8PSW main switch | ||
| Rated current(In) | A | 40, 50, 63, 80, 100 | |
| Rated voltage(ac)(Ue) | V | 240/415 | |
| Rated frequency(f) | Hz | 50/60 | |
| Nos. of poles(Execution) | 1P,2P,3P,4P | ||
| Rated short circuit breaking capacity | kA | - | |
| Utilization category | AC 22A | ||
| Magnetic release setting | - | ||
| Rated insulation voltage(Ui) | V | 660 | |
| Rated impulse voltage(Uimp) | kV | 4 | |
|
Electrical/Mechanical Endurance(no. of operations) |
Less than 32A | ||
| More than 32A | 10000 | ||
| Ambient temperature | ℃ | -5 to +55 | |
| Terminal capacity(max) | sq.mm | 25 | |
| Protection class | IP20 | ||
| Installation postion | Vertical/Horizontal | ||
| Mounting | Clip on DIN rail(35mm*7.5mm) | ||
| Case & Cover | Moulded, flame retardant thermoplastic meterial | ||
