Compact Single-channel PID Temperature Control Box
A temperature control box is an instrument panel that controls temperature and includes a temperature display unit, control adjustment device, and switch protection device. It features sensor input ports and control output ports, with three types of output options: relay switch output, solid-state control output, and power regulator adjustment output. It is mainly used in electric heating applications and temperature switch alarm scenarios.
-
Commonly available in single-phase and three-phase configurations, ranging from 1 kW to 20 kW, and complete temperature control cabinets can be customized for power ratings exceeding 20 kW.
-
It utilizes intelligent instruments or imported module PID control, achieving a temperature accuracy of ±1℃.
-
The input and output interfaces adopt standard terminal blocks for safe and convenient installation.
-
The control box is equipped with an earth leakage switch, which can provide additional alarm functionality and ensure full safety.
-
It has an aesthetically pleasing appearance with a modular design, allowing for easy disassembly, maintenance, and replacement.
-
Available in single-channel, multi-channel, and integrated touch screen models, compatible with various types of sensors.
Instrument accuracy: 0.5%
Rated frequency: 50~60Hz
Input type: K/E/J/PT100
Output type: 220V 2000W
Control method: Solid-state relay (SSR)
Operating temperature range: -10°C to 50°C
