G3DA4810 SSR 1 CHANNEL 10A
Home Products Solid State Relays (AC Switching)Din-rail mount SSR relaysG3DA4810 SSR 1 CHANNEL 10A
Product Details
G3DA4810 SSR 1 CHANNEL 10A
Integrated heat sink dissipates heat for simplified installation. Clips directly onto DIN rail and mounts to panels.
Switching Device | SCR |
Switching Type | Zero voltage |
Operating Voltage | 48 to 600 VAC |
Current Rating | 10 A |
Input Voltage Range | 4 to 32 VDC |
Input Current | 14-18 mA |
Mounting Style | DIN Rail |
Operating Temperature Range | -30 to 80 °C |
Storage Temperature Range | -30 to 100 °C |
Transient Overvoltage | 1200 Vpk |
Surge Current (PK MAX) | 300 A for 20ms |
On-State Voltage Drop at Rated Current (MAX) | 1.3 V |
Maximum I2T for Fusing (A2 SEC) | 375 |
Maximum Off-State Leakage Current at Rated Voltage | Auto tuning, PID |
Minimum Off-State DV/DT at MAX Rated Voltage | 500 V/µsec |
Maximum Turn-On Time | 1/2 cycle |
Maximum Turn-Off Time | 1/2 cycle |
Minimum Turn-On Voltage | 4 VDC |
Minimum Turn-Off Voltage | 1 VDC |
Weight | 50 g |
Contact Configuration | SPST-NO |
Outputs Channel | 1 |
