Inductive sensor LM30 angle connector type
Home Products Proximity Photoelectric SensorInductive proximity sensor (Cylinder type)Inductive sensor LM30 angle connector type
Product Details
Inductive sensor LM30 angle connector type
| Model NO. | Detection distance | Working voltage | Output | Flush | |
| Form | State | ||||
| LM30-3010NAT2 | 10mm | DC6-36V | NPN | NO | Flush |
| LM30-3010NBT2 | 10mm | DC6-36V | NPN | NC | Flush |
| LM30-3010NCT2 | 10mm | DC6-36V | NPN | NO NC | Flush |
| LM30-3010PAT2 | 10mm | DC6-36V | PNP | NO | Flush |
| LM30-3010PBT2 | 10mm | DC6-36V | PNP | NC | Flush |
| LM30-3010PCT2 | 10mm | DC6-36V | PNP | NO NC | Flush |
| LM30-3010LAT2 | 10mm | DC6-36V | Two wire system | NO | Flush |
| LM30-3010LBT2 | 10mm | DC6-36V | Two wire system | NC | Flush |
| LM30-2010AT2 | 10mm | AC90-250V | SCR Control label silicon | NO | Flush |
| LM30-2010BT2 | 10mm | AC90-250V | SCR Control label silicon | NC | Flush |
| LM30-3015NAT2 | 15mm | DC6-36V | NPN | NO | Non-flush |
| LM30-3015NBT2 | 15mm | DC6-36V | NPN | NC | Non-flush |
| LM30-3015NCT2 | 15mm | DC6-36V | NPN | NO NC | Non-flush |
| LM30-3015PAT2 | 15mm | DC6-36V | PNP | NO | Non-flush |
| LM30-3015PBT2 | 15mm | DC6-36V | PNP | NC | Non-flush |
| LM30-3015PCT2 | 15mm | DC6-36V | PNP | NO NC | Non-flush |
| LM30-3015LAT2 | 15mm | DC6-36V | Two wire system | NO | Non-flush |
| LM30-3015LBT2 | 15mm | DC6-36V | Two wire system | NC | Non-flush |
| LM30-2015AT2 | 15mm | AC90-250V | SCR Control label silicon | No | Non-flush |
| LM30-2015BT2 | 15mm | AC90-250V | SCR Control label silicon | NC | Non-flush |
