Low Power Short Range Millimeter-Wave Radar Module
Low Power Short Range Millimeter-Wave Radar Module
Feature

Low Power Short Range Millimeter-Wave Radar Module

Function



  • Target Presence Detection: Detects target presence and promptly wakes up smart devices.
  • Target Classification: Effectively distinguishes between stationary living beings, moving living beings, and other objects.
  • Area Sensing and Division: Defines and monitors the boundaries of the area of interest.
  • Target Tracking: Provides target movement trajectories for accurate positioning.
  • Intelligent Environment Learning: Eliminates environmental interference through learning and intelligent filtering mechanisms.
  • Obstruction Detection: Identifies scenarios where the radar is obstructed and alerts the user to clear the obstruction promptly.



Specification
Description Value
Operating Frequency 59~64GHz
Modulation Waveform FMCW
Structural Dimensions 30*15mm (non-AIP); 12*11mm (AIP)
Transmit Power 11dBm
Horizontal Viewing Angle ±60°
Vertical Viewing Angle ±30°
Detection Range 30m
Distance Accuracy 0.1m
Distance Resolution 0.3m
False Alarm Rate <5%
Working Voltage 3.3V/5V
Working Current

<200μA

Communication Port

UART、GPIO

Application

Product Details



  • Utilizing a 60GHz high-frequency millimeter-wave radar chip, it offers high detection precision and accuracy.
  • Designed for low power consumption, with operating current below 200μA, making it suitable for scenarios with strict power requirements and enhancing the battery life of smart devices.
  • Capable of human presence detection, providing intelligent wake-up functionality, and enabling smart interaction scenarios when integrated with smart devices.
