Discover the Greegoo GB Series Fast Recovery Diodes: The Ideal Choice for High-Performance Power Electronics

In the realm of power electronics, efficiency, speed, and reliability are paramount. The Greegoo GB Series Fast Recovery Diode (FRD) modules—including GB200NH40S (equivalent to ESB200NH40S), GB150NH40S (equivalent to ESB150NH40S), and GB100NH40S (equivalent to ESB100NH40S)—are designed for high-power applications such as industrial inverters, motor drives, and renewable energy systems. These diodes deliver precision, durability, and flexibility to meet diverse design needs.

Unique Advantages of the Greegoo GB Series

The GB Series diodes are engineered for high-voltage and high-current environments, utilizing a unified FD3 package to ensure excellent thermal performance and seamless system integration. Here are their core advantages:

1. Outstanding Electrical Performance

The GB Series offers multiple current ratings (200A, 150A, 100A), all supporting a 400V repetitive reverse voltage, catering to various power requirements. Key features include:

Low Forward Voltage Drop (1.05V typical, based on GB200NH40S data): Minimizes power loss for enhanced efficiency.

Ultra-Fast Reverse Recovery Time (150ns typical, based on GB200NH40S data): Supports high-frequency switching with reduced losses.

High Surge Capability: GB200NH40S handles up to 2800A non-repetitive surge current (GB150NH40S and GB100NH40S scale proportionally), ensuring reliability under peak loads.

These characteristics make the GB Series ideal for applications requiring efficiency and rapid switching.

2. Unified FD3 Package Design

GB200NH40S, GB150NH40S, and GB100NH40S share the same FD3 package, combining a compact footprint with superior thermal performance. The non-isolated package, paired with an efficient heatsink, ensures reliable operation in high-temperature environments (junction temperature range: -40°C to 125°C). The design supports M8 mounting screws (4.0 N·m torque) and M6 terminal screws (3.0 N·m torque) for easy integration into various systems.

3. Wide Range of Applications

The GB Series Ultra Fast Soft Recovery Diode Modules are versatile across multiple industries, sharing the same application scope as their equivalent ESB Series (ESB200NH40S, ESB150NH40S, ESB100NH40S):

Welding Equipment: Provides fast switching and high current handling for consistent performance.

Induction Heating: Enables efficient power delivery in high-frequency systems.

Uninterruptible Power Supplies (UPS): Ensures reliable operation for critical power backup systems.

Renewable Energy: Enhances the efficiency of solar inverters and wind turbine converters.

Their ability to reduce electromagnetic interference (EMI) and radio frequency interference (RFI) makes them a top choice for sensitive applications.

4. Reliable Performance Support

The GB Series (based on GB200NH40S data) offers comprehensive performance characterization, ensuring reliability during design. Detailed characterization of fast recovery parameters supports optimization for high-frequency applications, providing engineers with confidence in precise design.

Equivalence of GB Series and ESB Series

The Greegoo GB Series (GB200NH40S, GB150NH40S, GB100NH40S) is equivalent to the ESB Series (ESB200NH40S, ESB150NH40S, ESB100NH40S), sharing the same FD3 package design and electrical characteristics (e.g., 400V voltage and fast recovery time). The different models offer 200A, 150A, and 100A current ratings to meet diverse power needs, ensuring seamless replacement and consistent reliability.

Why Choose the Greegoo GB Series?

The Greegoo GB Series combines high power handling, ultra-fast recovery, and robust thermal management in a reliable, compact package. Its comprehensive recovery parameter characterization ensures stable performance, while the unified FD3 package simplifies system integration. Whether you're advancing industrial automation, optimizing welding equipment, or pioneering renewable energy solutions, the GB Series delivers exceptional performance.

Monthly production: 10,000 pieces, Low Cost, Fast delivery, OEM/ODM are welcome.
