Product Details
1 phase solid state relays
1 phase, chassis mounting, industrial relays with LED status indication and IP20 protection. AC operating frequency ragne 45-63 Hz. Rated insulation voltage is more than 4000Vrms.
Max. input current: 12mA for ZD3 and 15mA for ZA2
Min. operational current: 150mAOff state leakage current:＜3mA
Operating temperature:-20 to +70℃
Terminals: screw type with clamp
| Rated voltage | Control voltage | Rated operational current | ||
| 10A | 25 Amp | 40 Amp | ||
| Zero cross | 4-32Vdc | GDH1048ZD3C | GDH2548ZD3C | GDH4048ZD3C |
| 90-250Vac | GDH1048ZA2C | GDH2548ZA2C | GDH4048ZA2C | |
| Random switching | 4-32Vdc | GDH1048RD3C | GDH2548RD3C | GDH4048RD3C |
| 90-250Vac | GDH1048RA2C | GDH2548RA2C | GDH4048RA2C | |
| 50 Amp | 75 Amp | 100 Amp | ||
| Zero cross | 4-32Vdc | GDH5048ZD3C | GDH7548ZD3C | GDH10048ZD3C |
| 90-250Vac | GDH5048ZA2C | GDH7548RA2C | GDH10048RA2C | |
| Random switching | 4-32Vdc | GDH5048RD3C | GDH7548RD3C | GDH10048RD3C |
| 90-250Vac | GDH5048RA2C | GDH7548RA2C | GDH10048RA2C | |
Note: C1 - White color, C2 - Black color.
Inquiry
Need more information?
Contact us to request pricing, availability and customization options.
Related Products
Solid state Relay with Load Circuit Monitoring
60A to 500A 240/440V 4-32VDC load circuit and itself function monitoring solid state relay
View More
High current Solid State Relay 500-1600A
500-1600A Solid state relays, high current solid state relay
View More
40A 60A 80A 100A 120A Solid State Relay
