GD400SGY120C2S IGBT module

Features

• Low VCE(sat) Trench IGBT technology
• 10μs short circuit capability
• VCE(sat) with positive temperature coefficient
• Maximum junction temperature 175°C
• Low inductance case
• Fast & soft reverse recovery anti-parallel FWD
• Isolated copper baseplate using DBC technology

Typical Applications

• Inverter for motor drive
• AC and DC servo drive amplifier
• Uninterruptible power supply

GD400SGY120C2S IGBT Module
