Three Phase Bridge 130A 160A 300A
Home Products Diode Bridge ModuleSingle and 3 phase Diode Bridge moduleThree Phase Bridge 130A 160A 300A
Three Phase Bridge 130A 160A 300A
A range of extremely compact, encapsulated three phase bridge rectifiers offering efficient and reliable operation. They are intended for use in general purpose and heavy duty applications.
FEATURES
• Blocking voltage up to 1800 V
• High surge capability
• High thermal conductivity package, electrically insulated case
• Excellent power volume ratio
• 3600 VRMS isolating voltage
• Designed for industrial leve
VS-131MT160C VS-131MT180C VS-130MT160C VS-130MT180C Three phase diode bridge
VS-160MT160C VS-160MT180C VS-161MT160C VS-161MT180C three phase bridge diode module
VS-300MT160C VS-300MT180C three phase diode bridge module
Need more information?
Contact us to request pricing, availability and customization options.
