Inductive proximity sensor LMF5
Home Products Proximity Photoelectric SensorInductive proximity sensor (Rectangular type)Inductive proximity sensor LMF5
Product Details
Inductive proximity sensor LMF5
| Model NO. | Detection distance | Working voltage | Output | Flush | |
| Form | State | ||||
| LMF5-3002NA | 2mm | DC6-36V | NPN | NO | Flush |
| LMF5-3002NB | 2mm | DC6-36V | NPN | NC | Flush |
| LMF5-3002NC | 2mm | DC6-36V | NPN | NO NC | Flush |
| LMF5-3002PA | 2mm | DC6-36V | PNP | NO | Flush |
| LMF5-3002PB | 2mm | DC6-36V | PNP | NC | Flush |
| LMF5-3002PC | 2mm | DC6-36V | PNP | NO NC | Flush |
| LMF5-3002LA | 2mm | DC6-36V | Two wire system | NO | Flush |
| LMF5 -3002LB | 2mm | DC6-36V | Two wire system | NC | Flush |
| LMF5-3004NA | 4mm | DC6-36V | NPN | NO | Non-flush |
| LMF5-3004NB | 4mm | DC6-36V | NPN | NC | Non-flush |
| LMF5-3004NC | 4mm | DC6-36V | NPN | NO NC | Non-flush |
| LMF5-3004PA | 4mm | DC6-36V | PNP | NO | Non-flush |
| LMF5-3004PB | 4mm | DC6-36V | PNP | NC | Non-flush |
| LMF5-3004PC | 4mm | DC6-36V | PNP | NO NC | Non-flush |
| LMF5-3004LA | 4mm | DC6-36V | Two wire system | NO | Non-flush |
| LMF5 -3004LB | 4mm | DC6-36V | Two wire system | NC | Non-flush |
