Inductive proximity sensor LMF6
| Model NO. | Detection distance | Working voltage | Output | Flush | |
| Form | State | ||||
| LMF6-3008NA | 8mm | DC6-36V | NPN | NO | Flush |
| LMF6-3008NB | 8mm | DC6-36V | NPN | NC | Flush |
| LMF6-3008NC | 8mm | DC6-36V | NPN | NO NC | Flush |
| LMF6-3008PA | 8mm | DC6-36V | PNP | NO | Flush |
| LMF6-3008PB | 8mm | DC6-36V | PNP | NC | Flush |
| LMF6-3008PC | 8mm | DC6-36V | PNP | NO NC | Flush |
| LMF6-3008LA | 8mm | DC6-36V | Two wire system | NO | Flush |
| LMF6 -3008LB | 8mm | DC6-36V | Two wire system | NC | Flush |
| LMF6 -2008A | 8mm | AC90-250V | SCR control lable silicon | NO | Flush |
| LMF6-2008B | 8mm | AC90-250V | SCR control lable silicon | NC | Flush |
| LMF6-3010NA | 10mm | DC6-36V | NPN | NO | Non-flush |
| LMF6-3010NB | 10mm | DC6-36V | NPN | NO | Non-flush |
| LMF6-3010NC | 10mm | DC6-36V | NPN | NO NC | Non-flush |
| LMF6-3010PA | 10mm | DC6-36V | PNP | NO | Non-flush |
| LMF6-3010PB | 10mm | DC6-36V | PNP | NC | Non-flush |
| LMF6-3010PC | 10mm | DC6-36V | PNP | NO NC | Non-flush |
| LMF6-3010PA | 10mm | DC6-36V | Two wire system | NO | Non-flush |
| LMF6 -3010LB | 10mm | DC6-36V | Two wire system | NC | Non-flush |
| LMF6 -2010A | 10mm | AC90-250V | SCR control lable silicon | NO | Non-flush |
| LMF6-2010B | 10mm | AC90-250V | SCR control lable silicon | NC | Non-flush |
