Inductive sensor LMF370
Home Products Proximity Photoelectric SensorInductive proximity sensor (Rectangular type)Inductive sensor LMF370
Product Details
Inductive sensor LMF370
| Model NO. | Detection distance | Working voltage | Output | Flush | |
| Form | State | ||||
| LMF370-3040NA | 40mm | DC6-36V | NPN | NO | Non-flush |
| LMF370-3040NB | 40mm | DC6-36V | NPN | NC | Non-flush |
| LMF370-3040NC | 40mm | DC6-36V | NPN | NO NC | Non-flush |
| LMF370-3040PA | 40mm | DC6-36V | PNP | NO | Non-flush |
| LMF370-3040PB | 40mm | DC6-36V | PNP | NC | Non-flush |
| LMF370-3040PC | 40mm | DC6-36V | PNP | NO NC | Non-flush |
| LMF370-3040LA | 40mm | DC6-36V | Two wire system | NO | Non-flush |
| LMF370 -3040LB | 40mm | DC6-36V | Two wire system | NC | Non-flush |
| LMF370 -2040A | 40mm | AC90-250V | SCR Control label silicon | NO | Non-flush |
| LMF370-2040B | 40mm | AC90-250V | SCR Control label silicon | NC | Non-flush |
