Product Details

Three phase solid state contactors up to 80A

· Three-Phase solid-state contactors ratings from 16A to 60A @ 40-530 VAC
· 1200 Volts transient overvoltage
· Removable IP 20 touch-safe cover
· CE approved, RoHS/EMC compliant.
· LED input status indicator
· Strengthened current design for heavy industrial loads
· Designed in according with the requirements of IEC 62314

· Zero-crossing (resistive loads) or instantaneous (inductive loads) output

Part No.	Load Voltage Type	Operating Voltage	Current	Control Voltage Type	Control Voltage	Switch Mode	Phase
GTC4816DA	AC	40-530VAC	16A	AC/DC	12VDC/220VAC	Zero-crossing	3
GTC4816DAR	AC	40-530VAC	16A	AC/DC	12VDC/220VAC	Instant-On Switching	3
GTC4816DB	AC	40-530VAC	16A	AC/DC	12VDC/120VDC	Zero-crossing	3
GTC4816DBR	AC	40-530VAC	16A	AC/DC	12VDC/120VDC	Instant-On Switching	3
GTC4825DA	AC	40-530VAC	25A	AC/DC	12VDC/220VAC	Zero-crossing	3
GTC4825DAR	AC	40-530VAC	25A	AC/DC	12VDC/220VAC	Instant-On Switching	3
GTC4825DB	AC	40-530VAC	25A	AC/DC	12VDC/120VDC	Zero-crossing	3
GTC4825DBR	AC	40-530VAC	25A	AC/DC	12VDC/120VDC	Instant-On Switching	3
GTC4840DA	AC	40-530VAC	40A	AC/DC	12VDC/220VAC	Zero-crossing	3
GTC4840DAR	AC	40-530VAC	40A	AC/DC	12VDC/220VAC	Instant-On Switching	3
GTC4840DB	AC	40-530VAC	40A	AC/DC	12VDC/120VDC	Zero-crossing	3
GTC4840DBR	AC	40-530VAC	40A	AC/DC	12VDC/120VDC	Instant-On Switching	3
GTC4850DA	AC	40-530VAC	50A	AC/DC	12VDC/220VAC	Zero-crossing	3
GTC4850DAR	AC	40-530VAC	50A	AC/DC	12VDC/220VAC	Instant-On Switching	3
GTC4850DB	AC	40-530VAC	50A	AC/DC	12VDC/120VDC	Zero-crossing	3
GTC4850DBR	AC	40-530VAC	50A	AC/DC	12VDC/120VDC	Instant-On Switching	3
GTC4860DA	AC	40-530VAC	60A	AC/DC	12VDC/220VAC	Zero-crossing	3
GTC4860DAR	AC	40-530VAC	60A	AC/DC	12VDC/220VAC	Instant-On Switching	3
GTC4860DB	AC	40-530VAC	60A	AC/DC	12VDC/120VDC	Zero-crossing	3
GTC4860DBR	AC	40-530VAC	60A	AC/DC	12VDC/120VDC	Instant-On Switching	3
GTC4880DA	AC	40-530VAC	80A	AC/DC	12VDC/220VAC	Zero-crossing	3
GTC4880DAR	AC	40-530VAC	80A	AC/DC	12VDC/220VAC	Instant-On Switching	3
GTC4880DB	AC	40-530VAC	80A	AC/DC	12VDC/120VDC	Zero-crossing	3
GTC4880DBR	AC	40-530VAC	80A	AC/DC	12VDC/120VDC	Instant-On Switching	3

Model explanation:

G - GREEGOO, TC- THREE PHASE CONTACTOR, 48 - 40~530VAC, 16 - 16A, 25 - 25A, 40 - 40A, 50 - 50A, 60 - 60A, 80 - 80A, DA - 12VDC/220VAC, DB - 12VDC/120VAC, BLANK - ZERO CROSSING CONTROL, R - RANDOM CONTROL.
