Product Details

20A-125A rotary isolator switches with plastic enclosurePDF

Order # Pole No. Max. rated
uninterrupted
current (AC-23A)
Operational
rating power
380/440VAC (AC-23A)
Mount IP degree
GR203S 3P 20A 5.5KW SURFACE IP65
GR253S 3P 25A 7.5KW SURFACE IP65
GR323S 3P 32A 11KW SURFACE IP65
GR403S 3P 40A 15KW SURFACE IP65
GR633S 3P 63A 22KW SURFACE IP65
GR803S 3P 80A 30KW SURFACE IP65
GR1003S 3P 100A 37KW SURFACE IP65
GR1253S 3P 125A 45KW SURFACE IP65
GR204S 3P+N 20A 5.5KW SURFACE IP65
GR254S 3P+N 25A 7.5KW SURFACE IP65
GR324S 3P+N 32A 11KW SURFACE IP65
GR404S 3P+N 40A 15KW SURFACE IP65
GR634S 3P+N 63A 22KW SURFACE IP65
GR804S 3P+N 80A 30KW SURFACE IP65
GR1004S 3P+N 100A 37KW SURFACE IP65
GR1254S 3P+N 125A 45KW SURFACE IP65
