Capacitive Yarn Detector

Model

CG-40NB-E1/CG-40NB-F1

Yarn Type

POY/FDY/Cotton

Yarn Speed

Up to 2000m/min

Voltage

10-30V DC

Current

30mA

Output

PNP/NPN

Detection

Running／Break

Function

Muting＆Run by button

Connection

Plug with cable

Housing

Zn

Operating Temperature

10℃ to 50℃

Humidity

Up to 75%

Detection

Capacitive

Output

Short-circuit/Polarity

Mounting Pitch

32mm

Tolerance

+/- 0.2mm
