Inductive proximity sensor LMF22
Home Products Proximity Photoelectric SensorInductive proximity sensor (Rectangular type)Inductive proximity sensor LMF22
Product Details
Inductive proximity sensor LMF22
| Model NO. | Detection distance | Working voltage | Output | Flush | |
| Form | State | ||||
| LMF22-3002NA | 2mm | DC6-36V | NPN | NO | Flush |
| LMF22-3002NB | 2mm | DC6-36V | NPN | NC | Flush |
| LMF22-3002PA | 2mm | DC6-36V | PNP | NO | Flush |
| LMF22-3002PB | 2mm | DC6-36V | PNP | NC | Flush |
| LMF22-3002LA | 2mm | DC6-36V | Two wire system | NO | Flush |
| LMF22-3004NA | 4mm | DC6-36V | NPN | NO | Non-flush |
| LMF22-3004NB | 4mm | DC6-36V | NPN | NC | Non-flush |
| LMF22-3004PA | 4mm | DC6-36V | PNP | NO | Non-flush |
| LMF22-3004PB | 4mm | DC6-36V | PNP | NC | Non-flush |
| LMF22-3004LA | 4mm | DC6-36V | Two wire system | NO | Non-flush |
