Three phase bridge rectifier SQL 20/40/60/100A
| Type | I F | V F | V RRM | I RRM1 | I RRM2 | I FSM | Tj | Tstg | Gooling |
| A | V | V | mA | mA | A | ℃ | ℃ | ||
| SQL12 | 20 | 1.4 | 100-1400 | 0.07 | 0.6 | 120 | -40~ 125 | -40~ 130 | air gooling |
| SQL14 | 40 | 1.4 | 100-1400 | 0.09 | 0.8 | 240 | -40~ 125 | -40~ 130 | air gooling |
| SQL16 | 60 | 1.4 | 100-1400 | 0.13 | 5 | 360 | -40~ 125 | -40~ 130 | air gooling |
| SQL18b | 100 | 1.4 | 100-1400 | 0.2 | 20 | 360 | -40~ 125 | -40~ 130 | air gooling |
