CZ-3 waterproof limit switch
Home Products Switch & SwitchgearLimit SwitchCZ-3 waterproof limit switch
Product Details
CZ-3 waterproof limit switch
| Models | CZ-3101 | CZ-3102 | CZ-3103 | CZ-3104 | CZ-3110 | CZ-3111 | CZ-3112 | CZ-3113 | CZ-3169 |
| OF Max. |
1200gf
(11.77N)
|
1200gf
(11.77N) |
1200gf
(11.77N)
|
580gf
(5.69N)
|
1200gf
(11.77N)
|
1800gf
(17.65N)
|
1800gf
(17.65N)
|
1800gf
(17.65N)
|
150gf
(1.47N)
|
| RF Min. |
450gf
(4.41N)
|
450gf
(4.41N)
|
450gf
(4.41N)
|
150gf
(1.47N)
|
450gf
(4.41N)
|
450gf
(4.41N)
|
450gf
(4.41N)
|
450gf
(4.41N)
|
- |
| PT Max. | 1.8mm | 1.8mm | 1.8mm | 25 | 1.8mm | 1.8mm | 1.8mm | 1.8mm | 15 º |
| OT Min. | 3mm | 3mm | 3mm | 40 | 3mm | 3mm | 3mm | 3mm | - |
| MD Max. | 0.2mm | 0.2mm | 0.2mm | 3 | 0.2mm | 0.2mm | 0.2mm | 0.2mm | - |
| OP | 15.7 ± 1mm | 28.5 ±1mm | 28.5 ±1mm | - | 28.5± 1mm | 24.9 ±1mm | 34.3 ±1mm | 34.3 ±1mm | - |
Inquiry
Need more information?
Contact us to request pricing, availability and customization options.
