Fast Vacuum Contactors
Model | CNF-400A/1.14KV | CNF-630A/3.6KV | CNF-800A/3.6KV | CNF-1250A/3.6KV | CNF-1600A/3.6KV | CNF-2000A/3.6KV | CNF-2500A/3.6KV |
Rated voltage | 1140V | 3.6KV | 3.6KV | 3.6KV | 3.6KV | 3.6KV | 3.6KV |
Rated current: | 400A | 630A | 800A | 1250A | 1600A | 2000A | 2500A |
Short circuit breaking capacity | 4KA | 6KA | 6KA | 10KA | 10KA | 10KA | 10KA |
Withstand current 4s: | 4KA | 6.3KA | 8KA | 12.5KA | 16KA | 20KA | 25KA |
Mechanical life: | 10x106 cycles | 10x106 cycles | 10x106 cycles | 10x106 cycles |
10x106 cycles |
10x106 cycles | 10x106 cycles |
Electrical life (AC3): | 1x106 cycles | 1x106 cycles | 1x106 cycles | 1x106 cycles | 1x106 cycles | 1x106 cycles | 1x106 cycles |
Contacts distance: | 1.5±0.5mm | 3±0.5mm | 3±0.5mm | 3±0.5mm | 3±0.5mm | 3±0.5mm | 3±0.5mm |
Limit: | 1.5±0.5mm | 1.5±0.5mm | 1.5±0.5mm | 1.5±0.5mm | 1.5±0.5mm | 1.5±0.5mm | 1.5±0.5mm |
Making/closing time: | 5ms | 5ms | 5ms | 5ms | 5ms | 5ms | 5ms |
Control voltage: | 36/110/127/220/380V AC or DC |
This is a custom-made vacuum contactor, while orering, please indicate your requirement about application field, making or breaking time, control voltage and contacts etc.
