Product Details
CZ-7 Micro Switches
| Model | CZ-7 | CZ-7100 | CZ-7110 | CZ-7310 | CZ-7311 | CZ-7312 | CZ-7120 | CZ-7140 | CZ-7121 | CZ-7141 | CZ-7124 | CZ-7144 | CZ-7166 |
| Operating force | OF (Max.) | 600g | 600g | 600g | 600g | 600g | 150g | 220g | 180g | 240g | 200g | 280g | 120g |
| Release force | RF (Min.) | 100g | 100g | 100g | 100g | 100g | 40g | 60g | 50g | 80g | 60g | 100g | |
| Pre-travel | PT (Max.) | 2.0mm | 2.0mm | 2.0mm | 2.0mm | 2.0mm | 13.5mm | 8.5mm | 11.0mm | 6.5mm | 11mm | 6.5mm | 250mm |
| Over travel | OT (Min.) | 0.8mm | 5.0mm | 6.0mm | 6.0mm | 6.0mm | 4.0mm | 2.5mm | 3.0mm | 2.0mm | 3.0mm | 2.0mm | 11mm |
| Movement differential | MD (Max.) | 0.8mm | 0.8mm | 0.8mm | 0.8mm | 0.8mm | 3.2mm | 2.0mm | 2.4mm | 1.5mm | 2.4mm | 1.5mm | |
| Operating position | OP(mm.) | 30.5±0.8mm | 44±1.2mm | 21.8±1.2mm | 33.3±1.2mm | 33.3±1.2mm | 25±1mm | 25±1mm | 40±1mm | 40±1mm | 50±1.2mm | 50±1.2mm | |
| Free Position | FP | 35mm | 32mm | 46mm | 56mm |
Download
