SCR Power Regulator single phase for Transformer and Inductive load
HGW1 Series Single-Phase Inductive Load Thyristor Power Regulator
◎ Adopts pure analog circuit design, highly resistant to interference and highly reliable.
◎ Synchronized voltage pre-wired at the factory, no need for customers to select phase.
◎ Constant current control mode provides excellent control for transformer loads.
◎ Factory-built-in transformer with optional external transformer for secondary current control feedback.
Specification
| Model | Phase | Input voltage | Rated current |
Load (KW) | Weight (kg) |
Control mode | Control signal | |
| 220V | 380V | |||||||
| HGW1-1-4-060-P | 1Ph | 330-440V | 60A | 10 | 15 | 3 | Phase output | 4-20mA/0-10V |
| HGW1-1-4-080-P | 1Ph | 330-440V | 80A | 15 | 25 | 3 | Phase output | 4-20mA/0-10V |
| HGW1-1-4-100-P | 1Ph | 330-440V | 100A | 18 | 30 | 3 | Phase output | 4-20mA/0-10V |
| HGW1-1-4-125-P | 1Ph | 330-440V | 125A | 22 | 36 | 3.5 | Phase output | 4-20mA/0-10V |
| HGW1-1-4-150-P | 1Ph | 330-440V | 150A | 26 | 44 | 3.5 | Phase output | 4-20mA/0-10V |
| HGW1-1-4-175-P | 1Ph | 330-440V | 175A | 30 | 50 | 3.5 | Phase output | 4-20mA/0-10V |
| HGW1-1-4-200-P | 1Ph | 330-440V | 200A | 35 | 60 | 3.5 | Phase output | 4-20mA/0-10V |
| HGW1-1-4-060-Z | 1Ph | 330-440V | 60A | 10 | 15 | 3 | Zero output | 4-20mA/0-10V |
| HGW1-1-4-080-Z | 1Ph | 330-440V | 80A | 15 | 25 | 3 | Zero output | 4-20mA/0-10V |
| HGW1-1-4-100-Z | 1Ph | 330-440V | 100A | 18 | 30 | 3 | Zero output | 4-20mA/0-10V |
| HGW1-1-4-125-Z | 1Ph | 330-440V | 125A | 22 | 36 | 3.5 | Zero output | 4-20mA/0-10V |
| HGW1-1-4-150-Z | 1Ph | 330-440V | 150A | 26 | 44 | 3.5 | Zero output | 4-20mA/0-10V |
| HGW1-1-4-175-Z | 1Ph | 330-440V | 175A | 30 | 50 | 3.5 | Zero output | 4-20mA/0-10V |
| HGW1-1-4-200-Z | 1Ph | 330-440V | 200A | 35 | 60 | 3.5 | Zero output | 4-20mA/0-10V |
| HGW1-1-4-060-C | 1Ph | 330-440V | 60A | 10 | 15 | 3 | Constant current | 4-20mA/0-10V |
| HGW1-1-4-080-C | 1Ph | 330-440V | 80A | 15 | 25 | 3 | Constant current | 4-20mA/0-10V |
| HGW1-1-4-100-C | 1Ph | 330-440V | 100A | 18 | 30 | 3 | Constant current | 4-20mA/0-10V |
| HGW1-1-4-125-C | 1Ph | 330-440V | 125A | 22 | 36 | 3.5 | Constant current | 4-20mA/0-10V |
| HGW1-1-4-150-C | 1Ph | 330-440V | 150A | 26 | 44 | 3.5 | Constant current | 4-20mA/0-10V |
| HGW1-1-4-175-C | 1Ph | 330-440V | 175A | 30 | 50 | 3.5 | Constant current | 4-20mA/0-10V |
| HGW1-1-4-200-C | 1Ph | 330-440V | 200A | 35 | 60 | 3.5 | Constant current | 4-20mA/0-10V |
| HGW1-1-4-060-V | 1Ph | 330-440V | 60A | 10 | 15 | 3 | Constant voltage | 4-20mA/0-10V |
| HGW1-1-4-080-V | 1Ph | 330-440V | 80A | 15 | 25 | 3 | Constant voltage | 4-20mA/0-10V |
| HGW1-1-4-100-V | 1Ph | 330-440V | 100A | 18 | 30 | 3 | Constant voltage | 4-20mA/0-10V |
| HGW1-1-4-125-V | 1Ph | 330-440V | 125A | 22 | 36 | 3.5 | Constant voltage | 4-20mA/0-10V |
| HGW1-1-4-150-V | 1Ph | 330-440V | 150A | 26 | 44 | 3.5 | Constant voltage | 4-20mA/0-10V |
| HGW1-1-4-175-V | 1Ph | 330-440V | 175A | 30 | 50 | 3.5 | Constant voltage | 4-20mA/0-10V |
| HGW1-1-4-200-V | 1Ph | 330-440V | 200A | 35 | 60 | 3.5 | Constant voltage | 4-20mA/0-10V |
