ESB200NH40S ESB150NH40S ESB100NH40S Ultra-Fast Soft Recovery Diode Module

Features

Repetitive Reverse Voltage : VRRM = 400V
Low Forward Voltage Drop : VF(typ.) = 1.05V
Average Forward Current : IF(AV.) = 200A @ Tc = 100
Ultra-Fast Reverse Recovery Time : trr(typ.) = 150 ns
Extensive Characterization of Recovery Parameters
Reduced EMI and RFI
Non Isolation Type Package

Applications

Welding Machine
Induction Heating
UPS
