GCM-4A10P 4 Channel Output Solid State Relay
GCM-4A10P is applied by PLC or controller to switch the High-current Device. And with excellent isolate protection, the module can prevent PLC and controller is damaged by electronic interference.
Features
High isolation voltage ( 3750Vrms )
Both NPN and PNP input type can be applied
Every channel can operate 5A load
| Input | |
| Nominal voltage | 12-24VDC |
| Nominal operating current | 6mA |
| Min.Nominal voltage | 11VDC |
| Input type | NPN or PNP |
| Output | |
| Nominal switching capacity (resistive load) | 5A 220VAC @ 25℃ |
| Max.switching voltage | 440VAC |
| Max.Continuous current | 5A |
| Pulsed Current | 40A |
| Electrical characteristics | |
| Isolation voltage | 3750Vrms @AC,1min.,R.H.≤60%;10000Vrms @AC,1sec,in oil |
| Control type | Zero cross switching |
| Response time | ON<10ms; OFF<10ms |
| Status Indicating Display | Green LED |
| Conditions | |
| Ambient Operating Temperature Range | -20℃ to 80℃ |
| Ambient Storage Temperature Range | -40℃ to 100℃ |
