Stud Avalanche Diode SKNa 20
Features
Avalanche type reverse characteristic up to 1700
Hermetic metal case with glass insulator
Anode side threaded stud ISO M6x1
Cooling via metal plates or heatsinks
SKN: Anode to stud
IFRMS = 40 A (maximum value for continuous operation)
IFAV = 20 A (sin. 180; Tc = 93 ºC)
SKNa20-13 is 20A 1300V
SKNa20-17 is 20A 1700V
Typical Applications
DC supply for magnets or solenoids (brakes, valves, etc.)
Field coil supply for DC motors
Series connections for high voltage applications (dust precipitators)
