Three phase diode bridge module 400A 500A
Home Products Diode Bridge ModuleSingle and 3 phase Diode Bridge moduleThree phase diode bridge module 400A 500A
Product Details
Three phase diode bridge module 400A 500A
| VRSM | IDAV(Tcase= 100 oC,) | |
| VRRM | 400A | 500A |
| 600V | MDS-400-06F | MDS-500-06F |
| 800V | MDS-400-08F | MDS-500-08F |
| 1200V | MDS-400-12F | MDS-500-12F |
| 1400V | MDS-400-14F | MDS-500-14F |
| 1600V | MDS-400-16F | MDS-500-16F |
| 1800V | MDS-400-18F | MDS-500-18F |
