Product details
DF150AB120 DF150AB160 DF200AB120 DF200AB160 Three phase Power Diode Module
DF200AB80 DF200AB160 DF150AB80 DF150AB160
Feature & Advantages
- Three Phase Rectifier Bridge
- Isolated package
- Output DC current (200A)
- Tj Max)=150 C
- 22mm Height
- High reliability by unique glass passivation
- RoHS directive compliance
Applications
- AC DC Motor Drive
- AVR
- Switching for three phase rectification
- Welding Machine
