240U 240R Stud Diode
FEATURES
• Diffused diode
• Wide current range
• High voltage ratings up to 1200 V
• High surge current capabilities
• Stud cathode and stud anode version
• Hermetic metal case
• Designed and qualified for industrial level
TYPICAL APPLICATIONS
• Welders
• Power supplies
• Machine tool controls
• High power drives
• Medium traction applications
• Battery charges
• Freewheeling diodes
| TYPE NUMBER | VOLTAGE CODE | VRRM (V) | VRSM (V) | IRRM MAXIMUM AT TJ = TJ MAXIMUM (mA) | STUD | BASE |
| 240U80D | 80 | 800 | 900 | 15 | Normal
(cathode to stud) |
P:3/4" 20UNF-2A |
| 240U100D | 100 | 1000 | 1100 | 15 | Normal
(cathode to stud) |
P:3/4" 20UNF-2A |
| 240U120D | 120 | 1200 | 1300 | 15 | Normal
(cathode to stud) |
P:3/4" 20UNF-2A |
| 240R80D | 80 | 800 | 900 | 15 | Reverse
(anode to stud) |
P:3/4" 20UNF-2A |
| 240R100D | 100 | 1000 | 1100 | 15 | Reverse
(anode to stud) |
P:3/4" 20UNF-2A |
| 240R120D | 120 | 1200 | 1300 | 15 | Reverse
(anode to stud) |
P:3/4" 20UNF-2A |
For metric device M16 x 1.5 contact factory for custom-made.
