Standard Recovery Diode 6A 12A 16A 25A
Home Products Stud Semiconductor DeviceVishay Stud DiodeStandard Recovery Diode 6A 12A 16A 25A
Product Details
Standard Recovery Diode 6A 12A 16A 25A
| Type | IF(AV) | VFM/IFM | IFRMS | VRRM | IRRM | Rjc | M2 | Wt | Outline | |
| THS55℃ | 25℃ | |||||||||
| A | V | A | A | V | mA | ℃/W | N/m | kg | ||
| 6F | 6 | 1.1 | 18 | 9 | 200-1200 | ≤6 | ≤2.0 | ≤1.0 | 0.008 | DO-4 |
| 12F | 12 | 1.25 | 36 | 190 | 200-1200 | ≤6 | ≤1.2 | ≤1.0 | 0.008 | |
| 16F | 16 | 1.25 | 48 | 25 | 200-1200 | ≤12 | ≤1.2 | ≤1.0 | 0.008 | |
| 16HF | 16 | 1.25 | 48 | 25 | 200-1200 | ≤12 | ≤1.2 | ≤1.0 | 0.008 | |
| 25F | 25 | 1.1 | 75 | 40 | 200-1200 | ≤12 | ≤1.2 | ≤1.0 | 0.008 | |
| 25HF | 25 | 1.1 | 75 | 40 | 200-1200 | ≤12 | ≤1.2 | ≤1.0 | 0.008 | |
| 6FR | 6 | 1.1 | 18 | 9 | 200-1200 | ≤6 | ≤2.0 | ≤1.0 | 0.008 | DO-4 |
| 12FR | 12 | 1.25 | 36 | 190 | 200-1200 | ≤6 | ≤1.2 | ≤1.0 | 0.008 | |
| 16FR | 16 | 1.25 | 48 | 25 | 200-1200 | ≤12 | ≤1.2 | ≤1.0 | 0.008 | |
| 16HFR | 16 | 1.25 | 48 | 25 | 200-1200 | ≤12 | ≤1.2 | ≤1.0 | 0.008 | |
| 25FR | 25 | 1.1 | 75 | 40 | 200-1200 | ≤12 | ≤1.2 | ≤1.0 | 0.008 | |
| 25HFR | 25 | 1.1 | 75 | 40 | 200-1200 | ≤12 | ≤1.2 | ≤1.0 | 0.008 | |
Outline Dimensions
-casing-stud-diode.jpg)
DO-203AA (DO-4) Casing
