Product details

3 Phase Digital Thyristor Controller 125A

Product Features
◎ Utilizes MCU embedded microcontroller control technology and PID closed-loop control for 100% linear output.
◎ Three-phase full-control 6-pulse output, compatible with transformer loads or loads with neutral wire connection.
◎ Dual-channel input signal design: 0~5V, 0~10V, 4~20mA, or potentiometer limit, with direct switching.
◎ Fast-acting fuse combined with electronic transformer for dual overcurrent protection.
◎ Digital display for input, output, current, voltage, power, with one-key switching.

Part Numbers

Part Numbers	Phase	Input voltage	Current	Load Power (KW)		Weight (kg)	Control mode
Part Numbers	Phase	Input voltage	Current	220V	380V	Weight (kg)	Control mode
HGW5-4-4-125-P	3PH	380-440V	125A	40	68.5	4.4	Phase angle (constant voltage limiting current)
HGW5-4-4-125-Z	3PH	380-440V	125A	40	68.5	4.4	Zero crossing (Power regulating)
HGW5-4-2-125-P	3PH	110-220V	125A	40	68.5	4.4	Phase angle (constant voltage limiting current)
HGW5-4-2-125-Z	3PH	110-220V	125A	40	68.5	4.4	Zero crossing (Power regulating)
