Intelligent Thyristor Regulator Three phase HGW9 30A to 100A

HGW9 Series Three-Phase Intelligent Power Regulator

Product Features

◎ Three-row digital display, capable of separately showing three-phase current, voltage, and power.

◎ Equipped with both MODBUS TCP Ethernet communication and MODBUS RTU 485 communication interfaces.

◎ Single-channel universal input design, with one input port compatible with 4-20mA, 0-10V, and other signals simultaneously.

◎ Both current and voltage adopt RMS (effective value) display, closer to actual measurement values.

Specification

Model	Phase	Input voltage	Rated Current	Load Power(KW)		Weight (KG)	Control mode	Control signal
				220V	380V
HGW9-4-4-030-PF	3Ph	380-440V	30A	9.5	16.5	3.5	Selectable	Selectable
HGW9-4-4-040-PF	3Ph	380-440V	40A	12.5	20	3.5	Selectable	Selectable
HGW9-4-4-050-P	3Ph	380-440V	50A	15.5	27	3.5	Selectable	Selectable
HGW9-4-4-060-P	3Ph	380-440V	60A	19	33	3.5	Selectable	Selectable
HGW9-4-4-075-P	3Ph	380-440V	75A	23.5	41	3.5	Selectable	Selectable
HGW9-4-4-080-P	3Ph	380-440V	80A	25.5	44	3.5	Selectable	Selectable
HGW9-4-4-090-P	3Ph	380-440V	90A	28.5	49	3.5	Selectable	Selectable
HGW9-4-4-100-P	3Ph	380-440V	100A	32	55	3.5	Selectable	Selectable

HGW9-4-2-030-PF	3Ph	110-220V	30A	9.5	16.5	3.5	Selectable	Selectable
HGW9-4-2-040-PF	3Ph	110-220V	40A	12.5	20	3.5	Selectable	Selectable
HGW9-4-2-050-P	3Ph	110-220V	50A	15.5	27	3.5	Selectable	Selectable
HGW9-4-2-060-P	3Ph	110-220V	60A	19	33	3.5	Selectable	Selectable
HGW9-4-2-075-P	3Ph	110-220V	75A	23.5	41	3.5	Selectable	Selectable
HGW9-4-2-080-P	3Ph	110-220V	80A	25.5	44	3.5	Selectable	Selectable
HGW9-4-2-090-P	3Ph	110-220V	90A	28.5	49	3.5	Selectable	Selectable
HGW9-4-2-100-P	3Ph	110-220V	100A	32	55	3.5	Selectable	Selectable

HGW9-4-8-030-PF	3Ph	480-600V	30A	9.5	16.5	3.5	Selectable	Selectable
HGW9-4-8-040-PF	3Ph	480-600V	40A	12.5	20	3.5	Selectable	Selectable
HGW9-4-8-050-P	3Ph	480-600V	50A	15.5	27	3.5	Selectable	Selectable
HGW9-4-8-060-P	3Ph	480-600V	60A	19	33	3.5	Selectable	Selectable
HGW9-4-8-075-P	3Ph	480-600V	75A	23.5	41	3.5	Selectable	Selectable
HGW9-4-8-080-P	3Ph	480-600V	80A	25.5	44	3.5	Selectable	Selectable
HGW9-4-8-090-P	3Ph	480-600V	90A	28.5	49	3.5	Selectable	Selectable
HGW9-4-8-100-P	3Ph	480-600V	100A	32	55	3.5	Selectable	Selectable

Control mode selectable: P - phase angle constant voltage with current limiting; C - constant current; CV - constant power; Z - zero crossing cycle power regulating; ZV - fixed cycle zero crossing power regulating.

Control signal selectable: 4-20mA/0-20mA/0-5V/0-10V/1-5V/2-10V/Pot
