MD800 MD1000 MD1200 Anti-reverse Diode Modules
Anti-reverse diode modules (also known as blocking or anti-backflow modules) are crucial components used in solar PV systems, battery charging circuits, and DC power setups. They ensure current flows exclusively in one direction, preventing battery back-feeding into solar panels during overcast conditions or protecting delicate upstream circuitry against accidental reverse-polarity connections.
| Part numbers | IF(AV) | Tc |
VRRM |
| MD800-10 | 800A | 70℃ | 1000V |
| MD800-12 | 800A | 70℃ | 1200V |
| MD800-16 | 800A | 70℃ | 1600V |
| MD800-18 | 800A | 70℃ | 1800V |
| MD800-20 | 800A | 70℃ | 2000V |
| MD800-22 | 800A | 70℃ | 2200V |
| MD800-25 | 800A | 70℃ | 2500V |
| MD800-30 | 800A | 70℃ | 3000V |
| MD800-36 | 800A | 70℃ | 3600V |
| MD800-42 | 800A | 70℃ | 4200V |
| MD800-50 | 800A | 70℃ | 5000V |
| MD1000-10 | 1000A | 70℃ | 1000V |
| MD1000-12 | 1000A | 70℃ | 1200V |
| MD1000-16 | 1000A | 70℃ | 1600V |
| MD1000-18 | 1000A | 70℃ | 1800V |
| MD1000-20 | 1000A | 70℃ | 2000V |
| MD1000-22 | 1000A | 70℃ | 2200V |
| MD1000-25 | 1000A | 70℃ | 2500V |
| MD1000-30 | 1000A | 70℃ | 3000V |
| MD1000-36 | 1000A | 70℃ | 3600V |
| MD1000-42 | 1000A | 70℃ | 4200V |
| MD1000-50 | 1000A | 70℃ | 5000V |
| MD1200-10 | 1200A | 70℃ | 1000V |
| MD1200-12 | 1200A | 70℃ | 1200V |
| MD1200-16 | 1200A | 70℃ | 1600V |
| MD1200-18 | 1200A | 70℃ | 1800V |
| MD1200-20 | 1200A | 70℃ | 2000V |
| MD1200-22 | 1200A | 70℃ | 2200V |
| MD1200-25 | 1200A | 70℃ | 2500V |
| MD1200-30 | 1200A | 70℃ | 3000V |
| MD1200-36 | 1200A | 70℃ | 3600V |
| MD1200-42 | 1200A | 70℃ | 4200V |
| MD1200-50 | 1200A | 70℃ | 5000V |
