MD130 MD160 MD200 MD250 Anti-reverse Diode Modules
Anti-reverse diode modules (also known as blocking or anti-backflow modules) are crucial components used in solar PV systems, battery charging circuits, and DC power setups. They ensure current flows exclusively in one direction, preventing battery back-feeding into solar panels during overcast conditions or protecting delicate upstream circuitry against accidental reverse-polarity connections.
| Part numbers | IF(AV) | Tc |
VRRM |
| MD130-04 | 130A | 100℃ | 400V |
| MD130-06 | 130A | 100℃ | 600V |
| MD130-08 | 130A | 100℃ | 800V |
| MD130-10 | 130A | 100℃ | 1000V |
| MD130-12 | 130A | 100℃ | 1200V |
| MD130-16 | 130A | 100℃ | 1600V |
| MD130-18 | 130A | 100℃ | 1800V |
| MD130-20 | 130A | 100℃ | 2000V |
| MD130-25 | 130A | 100℃ | 2500V |
| MD160-04 | 160A | 100℃ | 400V |
| MD160-06 | 160A | 100℃ | 600V |
| MD160-08 | 160A | 100℃ | 800V |
| MD160-10 | 160A | 100℃ | 1000V |
| MD160-12 | 160A | 100℃ | 1200V |
| MD160-16 | 160A | 100℃ | 1600V |
| MD160-18 | 160A | 100℃ | 1800V |
| MD160-20 | 160A | 100℃ | 2000V |
| MD160-25 | 160A | 100℃ | 2500V |
| MD200-04 | 200A | 100℃ | 400V |
| MD200-06 | 200A | 100℃ | 600V |
| MD200-08 | 200A | 100℃ | 800V |
| MD200-10 | 200A | 100℃ | 1000V |
| MD200-12 | 200A | 100℃ | 1200V |
| MD200-16 | 200A | 100℃ | 1600V |
| MD200-18 | 200A | 100℃ | 1800V |
| MD200-20 | 200A | 100℃ | 2000V |
| MD200-25 | 200A | 100℃ | 2500V |
| MD250-04 | 250A | 100℃ | 400V |
| MD250-06 | 250A | 100℃ | 600V |
| MD250-08 | 250A | 100℃ | 800V |
| MD250-10 | 250A | 100℃ | 1000V |
| MD250-12 | 250A | 100℃ | 1200V |
| MD250-16 | 250A | 100℃ | 1600V |
| MD250-18 | 250A | 100℃ | 1800V |
| MD250-20 | 250A | 100℃ | 2000V |
| MD250-25 | 250A | 100℃ | 2500V |
Need more information?
Contact us to request pricing, availability and customization options.
