SCR Voltage Regulator three phase 30A with Fan cooling
Home Products SCR RegulatorsHGW3 Analog Indicator Basic typeSCR Voltage Regulator three phase 30A with Fan cooling
Specification
SCR Voltage Regulator three phase 30A with Fan cooling
| Mode | Phase | Input Voltage | Max. Current |
Load(KW) | Weight (KG) |
Control mode | Control signal | |
| 220V | 380V | |||||||
| HGW3-4-4-030-PF | 3PH | 330-440V | 30A | 9.5 | 16.5 | 2.0 | Phase Angle | 4-20mA |
| HGW3-4-4-030-PF1 | 3PH | 330-440V | 30A | 9.5 | 16.5 | 2.0 | Phase Angle | 0-10V |
| HGW3-4-2-030-PF | 3PH | 100-240V | 30A | 9.5 | 16.5 | 2.0 | Phase Angle | 4-20mA |
| HGW3-4-2-030-PF1 | 3PH | 100-240V | 30A | 9.5 | 16.5 | 2.0 | Phase Angle | 0-10V |
| HGW3-4-8-030-PF | 3PH | 480V | 30A | 9.5 | 16.5 | 2.0 | Phase Angle | 4-20mA |
| HGW3-4-8-030-PF1 | 3PH | 480V | 30A | 9.5 | 16.5 | 2.0 | Phase Angle | 0-10V |
